Maximum rated lifting weight 55t
41m main boom + 16m fixed jib, the widest operating range in the industry
Strong performance, leading the industry's 60t-level product performance
Crawler beam + counterweight with self-disassembly technology, no need the auxiliary crane when disassembly
Mainbody transport: weight <28.6t, width <3.0m, meet the requirmentof 1.2m pallet truck
The telescopic crawler chassis equiped the excavator's roller and shoes, and the main engine counterweight has a graded load technology (4-level), which is more adaptable to working conditions
The main boom function is upgraded, which can realize any telescopic function. Industry-leading work efficiency, working condition combination and adaptability
The core accessories are imported and domestic first-line brands with high reliability.
| 1.Max. lifting capacity | t | 55 |
| 2.Boom length | m | 41 |
| 3.Max. slewing speed | r/min | 2.0 |
| 4.Max. grade ability | % | 45 |
| 5.Max. lifting load moment | t.m | 2116.8 |
| 6.Engine rated power | kw | 165 |
| 7.Max. travel speed | km/h | 2.3 |
